100Gb/s CFP4 LR4 10km

Model NO.: 100Gb/s CFP4 LR4 10km Optical Receiver

Quantity:

Product Description
Application Description

- Specification -

Optical Characteristics

(Tested under recommended operating conditions,unless otherwise noted)

Parameter	Symbol	Unit	Min		Typ		Max		Notes
Optical Receiver Characteristics
Receive Rate for Each Lane		Gbps		25.78125		27.9525
Overload Input Optical Power	Pmax	dBm	5.5					3
Average Receive Power for Each Lane	Pin	dBm	-8.6			3		4
Receive Power In OMA for Each Lane	PinOMA	dBm				3
Difference in Receive Power in OMA between Any Two Lanes		dBm
Receiver Sensitivity in OMA for Each Lane	SOMA	dBm				-8.6		5
Stressed Receiver Sensitivity in OMA for Each Lane		dBm				-6.8		6,7

Notes:

1. The supply current includes CFP4 module’s supply current and test board workingcurrent.

2. Average launch power, each lane (min) is informative for 100GBase-LR4, not the principal indicator of signal strength.

3.The receiver shall be able to tolerate , without damage, continuous exposure to an optical input signal having this average power level

4. Average receive power, each lane (min) is informative and not the principal indicator

of signal strength. A received power below this value cannot be compliant; however, a value above this does not ensure compliance

5. Receiver sensitivity (OMA), each lane (max) is informative

6. Measured with conformance test signal at TP3 for BER=10-12

7. conditions of stressed receiver sensitivity test: vertical eye closure penalty for each lane is 1.8dB;stressed eye J2 jitter for each lane is 0.3UI; stressed eye J9 jitter for each lane is 0.47UI.
